Product Description
Stainless steel wire rope is a type of steel cable made by twisting multiple stainless steel wires together, mainly used in various occasions that require corrosion resistance, high strength, and wear resistance.
Product name: stainless steel wire rope
Product material: 304/316
stainless steel Model: 1*7 1*19 7*7 7*19 19*7 7*37
Customized American and European standards
Purpose: high-speed rail connection line, fishing boat steel wire rope net , clothes hanger steel wire rope
Stainless steel wire rope is widely used in construction, bridges, lifting, elevators, cable , marine engineering, mining, petrochemical, and other fields.
Product advantage
Advantage :
Corrosion Resistance: Due to the use of stainless steel materials, the wire rope has good corrosion resistance and is suitable for use in damp or chemically corrosive environments.
High Strength: Stainless steel wire rope has high tensile strength and can withstand significant pulling forces.
Wear Resistance: The hardness of stainless steel material is relatively high, thus it has good wear resistance.
High Temperature Resistance: Some stainless steel materials can maintain performance in high-temperature environments, making them suitable for high-temperature operations.
Flexibility: Wire ropes have good flexibility and can bend without easily breaking.
Long Service Life: Due to the aforementioned characteristics, the service life of stainless steel wire rope is usually longer than that of ordinary wire rope.
Safety: Stainless steel wire rope usually shows noticeable deformation before breaking, providing a certain safety warning for users.
Product Parameters
| structure | Size | Weight(100 meters/kg) | Safety load(KG) | Maximum load(kg) |
7*7 | 0.5 | 0.09 | 4.8 | 14.3 |
| 0.8 | 0.25 | 9.9 | 29.6 | |
| 1 | 0.39 | 19.0 | 57.1 | |
| 1.2 | 0.56 | 27.6 | 82.7 | |
| 1.5 | 0.88 | 43.2 | 129.6 | |
| 1.8 | 1.27 | 62.2 | 186.7 | |
| 2 | 1.57 | 76.5 | 229.6 | |
| 2.5 | 2.45 | 119.7 | 359.2 | |
| 3 | 3.53 | 172.4 | 517.3 | |
| 4 | 6.28 | 306.5 | 919.4 | |
| 5 | 9.82 | 479.3 | 1437.8 | |
| 6 | 14.14 | 690.1 | 2070.4 | |
| 8 | 25.15 | 1226.9 | 3680.6 | |
| 10 | 39.3 | 1917 | 5751.0 | |
| 12 | 56.59 | 2760.5 | 8281.6 |
Detailed Photos
